Which aluminium grade is truly the best? The 7000 series aluminium stands out for strength. It excels in aerospace, automotive, and high-performance parts. In this article, we explore its properties and compare key grades. You will learn how to choose the right aluminium for your projects.
The 7000 series aluminium is primarily a zinc alloy. Zinc provides the highest strengthening effect. Magnesium and copper enhance hardness and toughness. Trace elements like chromium and titanium stabilize microstructures. Together, they create a material with remarkable mechanical performance.
Yield strength: 300–500 MPa
Tensile strength: Up to 570 MPa
Hardness: High, superior to mild steel
These properties make it ideal for parts that face high stress or heavy loads.
Heat treatments, such as T6 temper, significantly improve 7000 series aluminium strength. T6 increases hardness and tensile strength but may reduce formability. Proper heat treatment ensures reliable performance in demanding applications.
7000 series offers fair corrosion resistance. It surpasses 2000 series alloys but lags behind 6000 series in marine environments. Stress corrosion cracking can occur if zinc and magnesium content is high.
Aerospace structural components
High-performance sports equipment
Automotive high-stress parts
Research requiring lightweight strength
Use protective coatings like anodizing or powder coating to enhance durability in corrosive environments.
Grade 7075 is the most recognized. It delivers the highest strength in commercial aluminium alloys. Cold forming is limited; heating is recommended. It supports hard anodizing and powder coating but resists bright color anodizing.
7050 offers better stress corrosion resistance than 7075, making it suitable for aerospace and fatigue-sensitive applications. Its strength is slightly lower but balanced by durability.
These grades provide specialized performance. For example, 7068 delivers extreme strength for high-stress applications, while 7022 balances machinability and strength for structural components.
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Corrosion Resistance | Machinability |
|---|---|---|---|---|
| 7075 | 503 | 572 | Fair | Moderate |
| 7050 | 470 | 540 | Good | Moderate |
| 7068 | 510 | 585 | Fair | Low |
| 7022 | 440 | 520 | Good | High |
7075: Choose for maximum strength
7050: Choose for fatigue-sensitive applications
7068/7022: Use for niche or customized requirements
Tips: Match grade selection to performance requirements and fabrication capabilities.
6000 series is versatile, with excellent corrosion resistance. Its strength is lower than 7000 series, making it better for construction and automotive parts that do not face extreme stress.
8000 series alloys serve highly specialized engineering. They can offer tailored strength, conductivity, or formability for research and advanced applications.
For high strength and lightweight design, 7000 series aluminium is ideal.
For general structural use, 6000 series suffices.
For specialty projects, consider 8000 series.
Engineers should weigh strength versus corrosion resistance for the specific environment.
Its strength exceeds mild steel while remaining lightweight. This makes it ideal for aerospace and high-speed machinery.
It resists wear, maintains hardness, and performs well under drilling and machining.
Can be forged, rolled, extruded, or cast. Tolerates complex shapes and large structural parts.
Efficiently transfers heat, useful in high-temperature or engine applications.Consider T6 or other temper options to balance hardness and machinability.
High zinc and magnesium content reduces stress corrosion resistance. Protective coatings are recommended.
Hardness makes forming difficult. Fine machining and heat treatment are often required.
Higher strength grades cost more than 6000 series but reduce weight and improve performance.
Stronger grades often have reduced corrosion resistance and are harder to process. A careful balance is key. Factor in fabrication complexity and maintenance costs before choosing high-strength alloys.
Identify if the part requires strength, corrosion resistance, or lightweight design.
Evaluate exposure to moisture, salt, or chemicals to determine the ideal corrosion resistance level.
Assess machinability, weldability, and forming requirements.
Consider ROI: higher upfront cost can save on material weight and maintenance. Create a grading checklist to compare performance, corrosion, and fabrication needs before procurement.
The 7000 series aluminium offers top strength for aerospace and automotive projects. Grades like 7075 provide maximum power, while 7050 improves corrosion resistance. Alumag's products deliver reliable performance and value. Comparing properties helps engineers select the right grade for every application.
A: 7000 series aluminium is a high-strength zinc alloy used in aerospace and automotive applications.
A: A 7000 series aluminium strength comparison shows it surpasses mild steel in tensile strength.
A: 7075 offers maximum strength, while 7050 improves corrosion resistance.
